RequirementsAMSI18
The RR011 is dedicated to modifications to the Engine Control Units in Renault/Dacia vehicles mostly on a bench. When purchasing RR011 you can expect to be able to do the following:

Reading and updating the EEPROM of the following ECUs:

EDC15C3
EDC15C13
EDC17 (can be read/updated if EP001 is active)
SIRIUS32
SID301
SIM32
SAFIR/SAFIR2/SAFIR200 (reading only)
IAW 6R.20
IAW 6R.30 (reading only)

Reading and updating the FLASH of the following ECUs:

EDC15C3
EDC15C13
EDC17 (can be read/updated if EP001 is active)
SIRIUS32
SID301
SIM32

Clearing IMMO code data for the following ECUs:

EDC15C3
EDC15C13
SIRIUS32
SID301
SAFIR/SAFIR2/SAFIR200
SIM32
IAW 6R.30

Adaptation of virgin Engine Control Module (ECM) for:

Clio IV
Twingo III
Trafic III
Logan II
Sandero II
Duster Ph2
Dokker
Lodgy

We supply all necessary pinouts in order to allow you to connect the ECUs on a bench.
N.B. Please note that you will require an AVDI interface with an active AMS in order to use this special function.
